    CE UKCA SAA Waterproof Electronic LED Driver 12w 12 Volt Power Supply 0.5a

    Ask Lasest Price
    Brand Name : Huawei
    Model Number : VUO-012-024A7
    Certification : CE CB ROSH SAA ETL CCC UKCA ERP BIS
    Price : Adjustable with Quantity
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 30000 pcs Per Month
    Delivery Time : 10-15days
    • Product Details
    • Company Profile

    CE UKCA SAA Waterproof Electronic LED Driver 12w 12 Volt Power Supply 0.5a

    CE UKCA SAA 12w led driver ac to dc 12 volt mini small waterproof power supply 12v 1a 24v 0.5a for underground light

    Product Advantages:
    1. Constant Voltage
    2. Waterproof IP67
    3. Aviation Grade Metal Case
    4. No Flicker, No Noise, Compatible With Various Controllers
    5. High Reliability, Long Validity Period
    6. Over-Voltage, Over-Current, Short-Circuit Protection


    Products descriptions

    ModelVUO-012-024A7
    OutputDC voltage24V
    Rated current0.5A
    Current range0~0.5A
    rated power12W
    Ripple & Noise (peak to peak)<400mV
    No-load voltage±0.5V
    Inputvoltage range100~265VAC
    Current47~63Hz
    Power factor0.5
    effectiveness(Typ.)82%
    Alternating current(Typ.)0.09A/220VAC
    ProtectionShort circuitProtection mode: hiccup mode, abnormal conditions can be automatically restored after removal
    overload1.5A
    environmentOperating temperature-30~+540℃ (Please refer to the load reduction curve)
    Protection classIP67 Suitable for outdoor and indoor use
    Storage temperature-40~+80℃
    Safety&EMCSafety standardsSuitable for EN61347-1;EN61347-2-13;SELV;IP67
    WITHSTAND VOLTAGEI/P-O/P:2KVAC,I/P-FG:2KVAC O/P-FG:0.5KVAC
    Tips1.If without specia explanation, all specifications are measured at an input of 220VAC, rated load, ambient temperature of 25 ° C . 2.Ripple & Noise Measurement Method: Use a 12 '' twisted pair, and the terminals are connected in parallel with 0.1uF and 47uF capacitors and tested at 20MHz bandwidth.



    FAQ:
    What are the different types of waterproof electronic LED drivers?
    There are several types of waterproof electronic LED drivers, including constant currentdrivers, constant voltage drivers, dimmable drivers, and programmable drivers.
    Constant current drivers deliver a constant current to the LED lighting fixtures, ensuring that the LED chips receive a consistent amount of electricity.
    Constant voltage drivers deliver a constant voltage to the LED lighting fixtures, ensuring that the LED chips receive a consistent voltage.
    Dimmable drivers allow LED lighting fixtures to be dimmed, providing greater control over lighting levels and energy consumption.
    Programmable drivers allow for customizable programming of the driver's output voltage and current, making them ideal for more complex lighting projects.

    Packaging:
    Packaging Details
    CARTONS,PALLETS
    High quality good selling ip67 12V waterproof constant current led driver switch mode power supply unit


    Port:Zhuhai port
